Model
SA-B1-IP8
sensor
1/2.7" black light CMOS sensor
Min.
illumination
Color:0.0001Lux @(F1.2,AGC ON); 0 Lux with IR
B/W: 0.0001 Lux @ (F1.2,AGC ON),0 Lux with IR
Shutter time
1/50(1/60)s to 1/10,000 s
Lens
HD lens 2.8mm
Lens mount
M12
Day&night
IR cut filter with auto switch
Max.image reolution
3840*2160
Frame rate
PAL: 8MP 3840*2160@15fps;
5MP 2880*1616@25fps;
4MP 2560*1440@25fps;
2MP 1920*1080@25fps
NTSC: 8MP 3840*2160@15fps;
setting
Saturation, brightness and contrast are adjustable through IE browser or client software.
Video compression
H.265AI/H.265+(compatible H.265/H.264) HighProfile, JPEG snapshot
Bite rate
0.1Mbps~8Mbps
Audio compression
G.711a
Storage
Network storage
Alarm
Motion detection, video loss, video block, etc.
protocol
TCP/IP, HTTP, DHCP, DNS, DDNS, PPPoE, SMTP, NTP, (HTTPS, SIP, 802.1x, IPv6)
Features
anti-flicker, dual-stream, heartbeat, password protection
Ethernet
1*10/100Mbps Ethernet port, RJ45 port
Audio I/O
0/0
temperature
-10C-+60C
humidity
10%-90% RH
Power supply
DC12V±10%/POE
IR range
1*White Light 1*Infrared Light“IR2”:20-30 meters
Consumption
MAX 3W
Material
Metal
Ingress Protection
IP66
Weight
Around 400g
